Integration Objects page

Integration Objects page looks:

integration objects

On this page you can:

  • synchronize integration objects of the required Agents (see Synchronization with Agent system section);

  • view last synchronization result (to do it click on Last Sync Result button);

    Last Sync Result button is available after synchronization and until page is refreshed.

  • view the integration objects of the selected Agent;

  • view deleted objects (to do it click on Browse deleted objects switcher) - it shows the objects that have been deleted on remote system after previous synchronization;

  • remove deleted objects (to do it select the object(s) and click on trash) - it deletes all related objects in scope of Testing Tool (e.g. recordings, test cases), and it doesn’t delete the object(s) from Change Tracking Tool → Tracked Objects page;

    You should switch view for deleted objects to be able to delete them.

  • delete test IFlows for CPI systems (to do it click on menu full and choose the action);

  • add, remove modules for PRO systems (to do it click on menu full and choose the action):

    • Add modules adds Figaf Agent Module or SAP Log Module (depending on chosen value of Messages logging approach option on Agent Configuration) to communication channel’s modules chain. Objects whose logging approach is ICO Logging need no modules and are skipped - the Integration Scenario update progress dialog lists them with the reason;

    • Remove modules is opposite to Add modules;

    • Remove ALL modules triggers removing from all objects. It is used while uninstallation;

      Add modules and Remove modules can be used only for primary objects (sender agreements for wildcard sender ICOs, wildcard receiver ICOs for receiver agreements, sender scenario in the bridges).

    • Modules management report downloads modules management history report with historical changes for communication channels made by Figaf Tool;

    • PI agent report downloads report with channels, operation mappings and function libraries configurations.

  • record messages to start configuring testing (to do it select the object(s) and click on Record messages button) - it opens Create recording requests dialog box;

  • create test case (to do it select the object and click Create Testcase) - it opens Test case creation page;

    Record messages and Create Testcase can be used only for primary objects (sender agreements for wildcard sender ICOs, wildcard receiver ICOs for receiver agreements, sender scenario in the bridges).

    Selected objects should be licensed for Testing (see Configure Object Licenses for details).

  • open details of integration objects (to do it click on recordings io or test cases io buttons) - it opens Integration Object Details page (see Integration Object Details page).
